The clearance ("air gap") of a Hall effect sensor is a precision specification. Do you recall the crankshaft sensor shims for the Vortec 350 and 4.3? On higher mileage engines, the wear in the crank bearings allowed the crank to move ever so slightly, mostly at high RPM, and the reluctor on the crank would actually contact the sensor tip. GM released a shim kit that was two .005" ring washers to space the CKP sensor away from the reluctor. You installed one and tested, then the other if one wasn't enough. That cam sensor is the same style and if it has visible slack, especially putting it AWAY from the reluctor, then I'd say that was the problem. If the PCM doesn't know where the cam is, it'll shut down all operations.
By the time the Vortec engines came about I was running shops and not wrenching, not even at home. Plus, as an advisor, I never came across that problem in my shops. Thanks for the info.

OP
OP
OR VietVet

OR VietVet

Multnomah Falls
Supporting Member
Military
Joined
Oct 8, 2014
Posts
20,989
Reaction score
37,483
Location
Willamette Valley
So, I replaced a passenger side mirror on a 2022 Prius this morning. Pretty easy job but I did have the cover of the fuse/relay box under the hood and found this: Ants and ant eggs. Kind of startled me when removed the cover and within 15 minutes, they were all gone and so were all the eggs.

20240127_100340 - Copy.jpg


Fless

Staff member
Super Moderator
Joined
Apr 2, 2017
Posts
12,161
Reaction score
24,800
Location
Elev 5,280
So, I replaced a passenger side mirror on a 2022 Prius this morning. Pretty easy job but I did have the cover of the fuse/relay box under the hood and found this: Ants and ant eggs. Kind of startled me when removed the cover and within 15 minutes, they were all gone and so were all the eggs.

View attachment 419980

So now those poor ants are homeless?

OP
OP
OR VietVet

OR VietVet

Multnomah Falls
Supporting Member
Military
Joined
Oct 8, 2014
Posts
20,989
Reaction score
37,483
Location
Willamette Valley
Have a drop off for tomorrow work. Gonna be here around 6 to drop. Gonna do the oil cooler assembly replacement. Will be taking off both the upper and lower intakes. Biggest PITA, when I have done these, is the oil bath clean up where the base of the oil cooler attaches. It is like a bath tub down there and can have about 1/2" to 3/4" of oil standing there. Thankfully, this is a transverse engine and is actually easier to do than the inline engines. The antifreeze coolant hose is a PITA to deal with on the inline engines compared to the transverse engines. As you can probably tell, I have done this particular repair before. Pics to come.

OP
OP
OR VietVet

OR VietVet

Multnomah Falls
Supporting Member
Military
Joined
Oct 8, 2014
Posts
20,989
Reaction score
37,483
Location
Willamette Valley
Did the 2017 Cherokee today and found a mangled boot on the snorkel, where it attaches at the throttle body. I cut the mangled part out and sealed fine after. You will see all the mixture of oil and coolant from under the oil cooler. All back together and runs great.

20240128_085000.jpg20240128_085004.jpg20240128_085014.jpg20240128_085020.jpg20240128_090943.jpg
