Let's see some pics of some lifted and leveled

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

Quackshack

TYF Newbie
Joined
May 28, 2016
Posts
5
Reaction score
0
You will rub both sides of bumper corner with the 20x10 -24. The front side where painted and need to trim the liner brace back. Also the rear fender side need NorCal mod to clear.

The -12 offset won't rub much and need some minor trim of the areas above.

I'm sorry, not trying to argue by any means, just trying to understand. So, I'll rub on the bumper is what you're saying? But I'm having custom bumpers built, wondering if we'd still run with bumpers built. What is the NorCal mod? Thanks again!


01Konvict

Boats n Hoes
Joined
Jan 16, 2011
Posts
2,740
Reaction score
691
Location
Raleigh/SML
So running 33x12.50 MTs on my 3" level will rub with 17x9 -12? Could I get away with trimming minor plastic?

First you need to be very cautious trying to do a 3" level. The angles will be terrible and need UCAs! Stick to 2.5. That offset won't need much trim but some plastic and maybe small NorCal mod.


01Konvict

Boats n Hoes
Joined
Jan 16, 2011
Posts
2,740
Reaction score
691
Location
Raleigh/SML
I'm sorry, not trying to argue by any means, just trying to understand. So, I'll rub on the bumper is what you're saying? But I'm having custom bumpers built, wondering if we'd still run with bumpers built. What is the NorCal mod? Thanks again!

It's cool dude just trying to warn people putting wide wheels on square fenders with minimal lift causing rub issues. If doing different bumper then your good but still need rear fender work. You can do the x10s with large version and different bumper.

http://www.duramaxforum.com/forum/n...s-3.html#/forumsite/20663/topics/69677?page=1


SilencedChevy

TYF Newbie
Joined
May 11, 2016
Posts
15
Reaction score
4
First you need to be very cautious trying to do a 3" level. The angles will be terrible and need UCAs! Stick to 2.5. That offset won't need much trim but some plastic and maybe small NorCal mod.
Well..... I already have the level and wheels. And looking at either the RCX or cognitive UCAs.


01Konvict

Boats n Hoes
Joined
Jan 16, 2011
Posts
2,740
Reaction score
691
Location
Raleigh/SML
Is the level kit a full 3" or parts that add up to 3" total? If parts then only do 2.5" Since you have wheels then put them on and see how much trimming you need.


SilencedChevy

TYF Newbie
Joined
May 11, 2016
Posts
15
Reaction score
4
Is the level kit a full 3" or parts that add up to 3" total? If parts then only do 2.5" Since you have wheels then put them on and see how much trimming you need.
Its a full 3" spacer. I have the spacers on and the wheels but I'm only running the stock 265/70/17 tires. I'm gonna get new tires here in a few months. But fell in love with the atturo trail blades that only come in 33x12.50/17. Instead of the 285/70/17 (33x11.5x17)


NGAneer

Full Access Member
Joined
Jan 21, 2014
Posts
1,785
Reaction score
1,023
Location
NWGA
This is what im trying to figure out! By the way, with your LED switchbacks, what wire did you put the resistor on to stop hyperflash? Is there a tutorial? I've had a set sitting in my garage for a while and my DRL just went out so it's time to rip the front end apart.

I'm not 100% sure which wire so try them out before you take my word on it. I'm about 80% sure I put the resistor on the "flash" wire, the proper term escapes me right now. It will be the brighter of the two colored wires in the harness leading to the bulb socket.

I believe my harness had a yellow, a brown and a black wire. I tapped in between the yellow and black I'm pretty sure. Just tap the wires, install the bulb and test it. If it's wrong, try tapping between the black and the other non-black wire. Good luck.


Lifted07

TYF Newbie
Joined
Jun 2, 2016
Posts
7
Reaction score
4
07 tahoe lt. 6 inch lift. Pro comp part# k1142bmx. Theyre actually the pro comp mx 2.75 coil overs. Rides wayyyy better then it did before the lift. Hopefully i have time today to finish trimming for the 35s. Il post pics after im done.edited_IMG_20160530_160259.jpg
@Lifted07 post the Tahoe here and detailed pics of the dirt logic coilovers
