Rosen PR-GM1210

[Ramiro0727]

I just installed the Rosen PR-GM1210 into my 2011 Chevy Tahoe LT with factory XM, Bose and OEM backup camera through the rear view mirror. The problem I'm having how do I get the back up camera to show on my Rosen instead of the rear view mirror. The instructions are kinda a vague on what to do. Has someone installed one of these and got the camera through the Rosen.

Thanks,
Ramiro

Sent from my SM-N950U using Tapatalk



[PG01]

@kbuskill
Cmon ken



[kbuskill]

Mine is an 08 and had the factory Navi before I installed the Rosen so all I had to do was cut the wires in the brown plug behind the radio and install an RCA onto them.

I can't remember the exact process for getting the video feed from the mirror (since mine didn't have it in the mirror) but it has been done many times.

I will see what I can dig up.

****EDIT****

Here you go...

Right above the drivers side kick panel and towards the door opening you will see a connector that has a white, blue and an uninsulated wire (shield). You can tap into the white and blue wires and run it to your nav unit. You will have an image in both the mirror and the nav unit or you can disconnect the connector and tap the wires that are routed behind the kick panel and run to your nav unit and you will have video in the nav unit only.

Hope that helps you out.



[Ramiro0727]

Mine is an 08 and had the factory Navi before I installed the Rosen so all I had to do was cut the wires in the brown plug behind the radio and install an RCA onto them.

I can't remember the exact process for getting the video feed from the mirror (since mine didn't have it in the mirror) but it has been done many times.

I will see what I can dig up.

Any help is greatly appreciated.

Ramiro

Sent from my SM-N950U using Tapatalk



[kbuskill]

Mine is an 08 and had the factory Navi before I installed the Rosen so all I had to do was cut the wires in the brown plug behind the radio and install an RCA onto them.

I can't remember the exact process for getting the video feed from the mirror (since mine didn't have it in the mirror) but it has been done many times.

I will see what I can dig up.

****EDIT****

Here you go...

Right above the drivers side kick panel and towards the door opening you will see a connector that has a white, blue and an uninsulated wire (shield). You can tap into the white and blue wires and run it to your nav unit. You will have an image in both the mirror and the nav unit or you can disconnect the connector and tap the wires that are routed behind the kick panel and run to your nav unit and you will have video in the nav unit only.

Hope that helps you out.

Just a bump because I edited my last post instead of posting again.



[Ramiro0727]

Just a bump because I edited my last post instead of posting again.

Thank you kbuskill. I will take a look at it tomorrow morning if it isn't raining. So basically I can connect a RCA cable to those 2 wires and then hook it up to my Rosen and I should have rear view camera on my unit?

Ramiro



[kbuskill]

Thank you kbuskill. I will take a look at it tomorrow morning if it isn't raining. So basically I can connect a RCA cable to those 2 wires and then hook it up to my Rosen and I should have rear view camera on my unit?

Ramiro

Yes that is correct.

Let us know how it works out for you.



[Ramiro0727]

Yes that is correct.

Let us know how it works out for you.

Sure will kbuskill. Thank you



[PG01]

And no props for pete....damn shame...



[swathdiver]

And no props for pete....damn shame...

Still wound up from the drive or don't you ever sleep?
