What did you do to your NNBS GMT900 Tahoe/Yukon Today?

[swathdiver]

You're not wrong and neither am I, the boxes can be labeled differently.



[Sam Harris]

Lights on and off:

View attachment 216782 View attachment 216783

Looking great. Are these OEM? Who’s the manufacturer?


Sent from my iPhone using TapaBlah



[PG01]

Something doesn't add up here, either you are wrong or my fuse box labels are messed up. My #66 is WSW/HTR - Windshield Washer Solvent Heater (60A) which does't have a fuse in and #71 is LGM - Lift Gate Motor (30A) don't think either of them have anything to do with TBC

View attachment 216789
You're not wrong and neither am I, the boxes can be labeled differently.

The way you have it is the way it goes. Different years may have changed. Easy to tell , grab your dvom and hit the rear trailer connector... if you got power, done.



[Doubeleive]

I didn't have to add a fuse on my 2012, hooked them up and they worked



[PG01]

I didn't have to add a fuse on my 2012, hooked them up and they worked

Max tow pkg comes with jcase fuse but you still have to hook up the battery charge wire if you want charging in the rear



[Chrismnj]

View attachment 216789
You're not wrong and neither am I, the boxes can be labeled differently.

So safe to say that

I didn't have to add a fuse on my 2012, hooked them up and they worked

that's what got me confused plus I came across the picture that Pete posted, but like he said "Different years may have changed" so in my case no need to add fuse and fender wire goes to the left post and wire closer to the engine goes to right post closer to the fender criss cross.



[swathdiver]

Mine didn't come with the J-case fuse, says so in the book. GM must've added it later. Not having the fuse allows it to run a certain way, the details escape me at the moment, sleep deprived again.



[Chrismnj]

here is my wiring, I did put tubing on it.



[PG01]

here is my wiring, I did put tubing on it.

View attachment 216796

Beautiful, just beautiful...







Edit: im being my normal wiseass self fyi....



[89Suburban]

Looking great. Are these OEM? Who’s the manufacturer?


Sent from my iPhone using TapaBlah

They are made in Taiwan Eagle Eyes

https://www.1aauto.com/chevy-headlight-pair/i/1alhp00559?f=349278&y=2007
