What did you do to your NNBS GMT900 Tahoe/Yukon Today?

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

HiHoeSilver

Away!
Joined
Feb 28, 2017
Posts
10,918
Reaction score
14,572
Location
Chicago
I'm no brake engineer but I question the notion of slots in rotors acting as a cutting area on pads.

These slots appear to be valleys without edges that are raised, or proud, of the flat rotor surface, and they are angled relative the the pads' passing over them. Can they truly serve to cut the pad? Very curious.

It's been my understanding that slotted rotors perform a bit better, but not dramatically better, than solid surface rotors because they facilitate better heat dispersion and minimize glazing, not because they facilitate better bite by virtue of cutting action.

Discuss.

Wholeheartedly agree with your last paragraph. The "cutting" action is certainly not the primary intended function of the slots. I do believe, however, that it happens. Thus the extra dust. Like @iamdub said, you're squishing the pad in there with constant applied pressure. This means that the edge doesn't need to be proud to act as a 'blade'. The pad material is also key to this equation. Think of what it would look like if you pressed a sponge against one of those spinning slots.


08HoeCD

Full Access Member
Joined
May 6, 2016
Posts
2,052
Reaction score
1,931
True, the better quality slotted rotors have slots with more of a radiused edge and angled wall than just a sharp corner. But, it's still a flat rotor surface that meets a void. The pad material, on a microscopic level, is still deflecting (being "squished") into this void. The harder the braking- the more that is squished into the void and the more material that is shaved. Yes, this provides more friction. But the primary function of the slot is to evacuate the gasses and heat formed under braking while channeling in ambient air- all which help to cool the rotor and pad which prevents glazing, fading and warping.

I'm a believer in their function. Years back, when cryo-tempered rotors were new to the general market, Powerslot teamed up with a cryogenics company to produce their "Frozen Rotors" line. I had one of the first, if not THE first set on my S10. I was a total ******* to those rotors for 11 years/70,000 miles until I sold the truck. Went through 3 sets of Hawk HP pads (never turned the rotors). I could stand on the brake pedal from 120MPH+ and never get so much as a pull or shimmy in the steering wheel and the brakes bit just as hard as always. The last 20,000 miles I had the truck, the pads were being squished even harder by a hydrabooster. The only thing I ever noticed after all this braking asshattery was a notably heavier coating of dust on the wheels.

I'll use my soapbox time here to give my review on PowerStop rotors. I thought the cryo-tempered rotors from PowerStop were the same as the Frozen PowerSlot. I don't believe they are, or maybe the quality of the base rotor is less. I think PowerStop, PowerSlot, Stop Tech, etc. are all one and the same, using Centric rotors. Assuming I was replicating what I had on my S10, I installed some cryo-tempered PowerStops and Hawk LTS pads (LTS since it's a full-size vehicle). I performed a break-in process by combining PowerStop and Hawk's recommended procedures as they were a little different but not really conflicting. The brakes felt great with more bite than stock and the warping was gone. A few days later, I drove to Tampa, Florida. While slowing down to a red light, the damned warping was back. I hadn't done ANY hard braking. It was less than 1,000 miles, 800+ of which was interstate driving with no brake use, and no hard braking before they started their bucking shit again. I keep seeing positive reviews on R1 rotors so I think I'm gonna give them a shot. These bite great and all, but I can't stand the feelings of warped rotors.

Wholeheartedly agree with your last paragraph. The "cutting" action is certainly not the primary intended function of the slots. I do believe, however, that it happens. Thus the extra dust. Like @iamdub said, you're squishing the pad in there with constant applied pressure. This means that the edge doesn't need to be proud to act as a 'blade'. The pad material is also key to this equation. Think of what it would look like if you pressed a sponge against one of those spinning slots.

I'm not buying 100% of what you gents are selling me, but since I'm no mechanical engineer I'm just gonna say, "okay."

;)


HiHoeSilver

Away!
Joined
Feb 28, 2017
Posts
10,918
Reaction score
14,572
Location
Chicago
I'm not buying 100% of what you gents are selling me, but since I'm no mechanical engineer I'm just gonna say, "okay."

;)

Here's the plan. You put one solid and one slotted rotor on your truck. Same pads on both. Check the dust in 2 weeks. Compare. Document. Let us know what happens.

:happy107:


08HoeCD

Full Access Member
Joined
May 6, 2016
Posts
2,052
Reaction score
1,931
Here's the plan. You put one solid and one slotted rotor on your truck. Same pads on both. Check the dust in 2 weeks. Compare. Document. Let us know what happens.

:happy107:

Great idea to test the theory!

But this kid ain't doing it. Lol


08grey

Full Access Member
Joined
Jun 17, 2012
Posts
4,596
Reaction score
725
I got my cryogenic rotors from amazon for like 120 a rotor. This was to replace the r1 with the hawk pads. The cryogenic are better I run them with the akebono pads and are happy.

Sent from my SM-G950U using Tapatalk


kbuskill

***CAUTION*** I do my own stunts!
Joined
Mar 11, 2017
Posts
5,312
Reaction score
8,331
Location
NE. FL.
I removed my headlights and wet sanded and clearcoated them with 2K clear and installed white/amber LED switchbacks in the parking lights/turn signals with resistors and also replaced the high beam bulbs with 100 watt bulbs and replaced the low beam HIDs I had with some better Morimoto bulbs. I am pretty happy with the out come for now..... until my next trick (project).... lol


PG01

Supporting Member
Joined
Nov 6, 2016
Posts
14,967
Reaction score
18,571
Location
Up here to the right
I removed my headlights and wet sanded and clearcoated them with 2K clear and installed white/amber LED switchbacks in the parking lights/turn signals with resistors and also replaced the high beam bulbs with 100 watt bulbs and replaced the low beam HIDs I had with some better Morimoto bulbs. I am pretty happy with the out come for now..... until my next trick (project).... lol
:pics-stfu:
