Whipple 2.3L Supercharger Installation on 2007 Yukon XL Denali (6.2L L92 Motor)

[Joseph Garcia]

Awesome build thread !
Do you have any pics of how and where the intercooler is mounted
and where the pump and lines run?
I see the coolant resevoir located on the pass side up high.
Want to kinda compare it to my edelbrock EForce SC, that I actually took off

The intercooler is located in front of the motor's coolant radiator. The intercooler's pump is located on the passenger side, just below the headlights. Unfortunately, I do not have a photo of the intercooler setup, looking from the top down, but there is a photo of the intercooler being attached in front of the motor's coolant radiator on post #7 in this thread.
