2004 6.0 NV4500 Tahoe

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

OP
OP
Dantheman1540

Dantheman1540

Full Access Member
Joined
Feb 13, 2020
Posts
4,856
Reaction score
10,502
Location
Sugar Loaf Mountain
Swapped a bad trans mount on my Tahoe and buddies 408 Denali yesterday. Pretty easy task and cheap parts. If this one goes bad then I'll find a Polyurethane mount.

Of course I had to reengineer the direct of one cross member bolt due to the wideband sensor being in the way.

20200608_184950.jpg 20200608_183515.jpg 20200608_184738.jpg 20200608_184924.jpg 20200608_180719.jpg


Rocket Man

Mark
Supporting Member
Joined
Dec 25, 2014
Posts
26,004
Reaction score
50,862
Location
Oregon
OP
OP
Dantheman1540

Dantheman1540

Full Access Member
Joined
Feb 13, 2020
Posts
4,856
Reaction score
10,502
Location
Sugar Loaf Mountain
They were both bad?

Mine was completely torn, the denali had become more difficult to shift and the trans appeared to be moving a lot side to side so we thought it was the mount. Pulled the old mount and it was not completely torn like most failed mounts, it was just kinda dry and shriveled. Had not planned to do the denali mount but after disassembling the Hurst shifter and inspecting everything else that seemed to be the only issue. It helped considerably but I think he needs to get an extended clutch master rod like I have or flush/bleed the clutch.

OP
OP
Dantheman1540

Dantheman1540

Full Access Member
Joined
Feb 13, 2020
Posts
4,856
Reaction score
10,502
Location
Sugar Loaf Mountain
