GM 6L80 Transmission Information Thread

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

OP
OP
NickTransmissions

NickTransmissions

Sin City
Supporting Member
Joined
Mar 9, 2023
Posts
1,083
Reaction score
2,597
Location
The transmission bench
So with those two gallon jugs that I just posted, why does only the one say Full Synthetic?
My guess (and that's literally what it is as i really dont know) is that the first label simply assumes the customer already knows Dex6 is full syn or its perhaps sold only to dealership and/or other service centers while the second one is labeled for general retail sale and is labled so everyone knows it's synthetic and not conventional fluid. :shrug:


strutaeng

Full Access Member
Joined
Aug 10, 2023
Posts
1,136
Reaction score
2,338
Location
Dallas, Texas
@NickTransmissions I started watching your videos. That's some great information to share. Thank you.

I own several GMT800s and rebuilt few 4L80e units. I bought an Express passenger van my wife daily drives. It's a 2020 and has around 12,000 miles with the 6L90e. I have a few questions for you if you don't mind:

1. Was the torque converter ever improved from GM on late production units? Doesn't sound like it? At what mileage should you recommend to replace it?

2. Is there an aftermarket torque converter you recommend?

3. What can be done from a maintenance perspective to help prolong the life of the 6L80/90? On the LS1TECH forum there's a member that was previously one of the Hydramatic engineers for GM. IIRC, he recommended fluid changes at 25,000 miles for this transmission.

4. Do you also recommend the modification to the ECU tune that limits TCC slippage? Seems like a common modification with the HP Tuners crowd, although I don't really know the details. I think there's something related to AFM that also gets modified on vehicles that had it?

5. The cooler thermostat bypass delete kit seems like a good idea since it will minimize the chance of overheating?

I may attempt to rebuild a 6 speed in the future, mostly to learn about them. They seem like cool units. I just need a big stash of cash for tools, a core (later model seems better?) and a rebuild kit.

Thanks in advance.

OP
OP
NickTransmissions

NickTransmissions

Sin City
Supporting Member
Joined
Mar 9, 2023
Posts
1,083
Reaction score
2,597
Location
The transmission bench
@NickTransmissions I started watching your videos. That's some great information to share. Thank you.
You're welcome, man and thank you for the kind words...I'll be putting out more vids on these units over the course of the next few weeks - please subscribe if you haven't done so already :)
Here's my responses in red:

1. Was the torque converter ever improved from GM on late production units? Doesn't sound like it? At what mileage should you recommend to replace it?
Not that I'm aware of - same design throughout the production run (06-21)

2. Is there an aftermarket torque converter you recommend? I'd go with any reputable converter builder who installs a .050+ converter clutch (my builder uses Borg Warner .070" high energy converter clutches) as well as offers billet covers as the two most common problem areas are that clutch and warpage in the covers. Yank, Circle-D, TCI, Florida Torque Converter. There's many more but those come to mind.
3. What can be done from a maintenance perspective to help prolong the life of the 6L80/90? On the LS1TECH forum there's a member that was previously one of the Hydramatic engineers for GM. IIRC, he recommended fluid changes at 25,000 miles for this transmission. Yep, VortecIROC - he and MaroonMonsterLS1 were both GM powertrain engineers and agree with their advice 100% (I say 25k-35k is a good cadence).

4. Do you also recommend the modification to the ECU tune that limits TCC slippage? Seems like a common modification with the HP Tuners crowd, although I don't really know the details. I think there's something related to AFM that also gets modified on vehicles that had it? Many of my customers tune out the TCC apply in 1st-4th gear and only have it come on in the two overdrive gears as having it work so hard in part-throttle stop and go driving stresses it more than it saves in terms of heat reduction. Speaking of which (see below)

5. The cooler thermostat bypass delete kit seems like a good idea since it will minimize the chance of overheating? Absolutely - run that kit or flip the pill (youtube has several vids on the procedure and I'll do one as well if I can grab a complete CBV assembly out of the yard.
Hope that helps!


SpyShops212

Full Access Member
Joined
Jan 29, 2022
Posts
372
Reaction score
347
Nick when my 10 speed fails do you work on them? How good are they and how many miles should the 10 speed last. On my 2008 Speed Escalade my transmission failed at 155k. Is the 10 speed better made and will it last longer. My truck is babied. I never peeled out & changed my fluid and filter at the dealer on time.

OP
OP
NickTransmissions

NickTransmissions

Sin City
Supporting Member
Joined
Mar 9, 2023
Posts
1,083
Reaction score
2,597
Location
The transmission bench
Nick when my 10 speed fails do you work on them? How good are they and how many miles should the 10 speed last. On my 2008 Speed Escalade my transmission failed at 155k. Is the 10 speed better made and will it last longer. My truck is babied. I never peeled out & changed my fluid and filter at the dealer on time.
Hi @SpyShops212 , I'm not super familiar with them, haven't gone hands on with one yet but have researched them (and the 8speeds) as I may take one or both transmission families on in the near future. From what I understand, the 10-speed has some improvements that address some of the pattern failures seen in the 8L45s/90s but like all transmissions, will have it's share of warts.

Are you located in or around Vegas?
