Rocket Man's 02 Denali Build Thread AKA "THE BEAST"

[Rocket Man]

Whatever you go with make sure you measure the plunge depth of the converter to make sure its fully seated on the pump and once bolted up measure the spacing of the converter pads to the plate. Getting the spacing right will keep you from busting the pump in the converter (not fully seated on trans) and pulling the converter off the pump (too much spacing from pads to plate.).



Sent from my SAMSUNG-SM-T377A using Tapatalk

I hope I can figure out what you mean when I start working on it. This will be my first time installing an automatic trans. I also just went ahead and ordered a new TruCool Max in case I can't get the other one flushed good. No sense taking any chances and it's only $100 or so. If I don't need it I'll send it back.



[sumo]

The performa build should come me with a cooler if i Remember correctly taking to them.



[Rocket Man]

The performa build should come me with a cooler if i Remember correctly taking to them.

I see that now, it's in the FAQs but they don't say which one.



[bottomline2000]

I decided on the TCI flexplate 399753. It's a bit more expensive but I don't want to have to pull the trans because I went cheap. And I ordered ARP bolts but they say they're .880. Are you saying those are the wrong ones? They're for the 6.0 LS-based engines.

Edit: I just noticed that it looks like TCI includes mounting hardware so I'll see what they send.

I was referring to the flexplate to converter bolts when I said the 8.8 vs 12.9. Its a hardness rating and my PI converter came with 8.8 rated bolts that were useless and I reused my 12.9 bolts which aren't ARP. I don't think ARP has hardness issues with anything they make. My ARP flexplate to crank bolts are these..https://www.summitracing.com/oh/par...hopping-_-srese1-_-arp&ibanner=MobileSwitchNo

Sent from my SAMSUNG-SM-T377A using Tapatalk



[Rocket Man]

I was referring to the flexplate to converter bolts when I said the 8.8 vs 12.9. Its a hardness rating and my PI converter came with 8.8 rated bolts that were useless and I reused my 12.9 bolts which aren't ARP. I don't think ARP has hardness issues with anything they make. My ARP flexplate to crank bolts are these..https://www.summitracing.com/oh/par...hopping-_-srese1-_-arp&ibanner=MobileSwitchNo

Sent from my SAMSUNG-SM-T377A using Tapatalk

Those are the ARP bolts I ordered, the 244-2901. I'm hoping the FTI converter comes with the correct flexplate to converter bolts but if it doesn't, what should I have on hand?
edit; found them, ARP 230-7305 set of 6. Ordered.



[bottomline2000]

Those are the ARP bolts I ordered, the 244-2901. I'm hoping the FTI converter comes with the correct flexplate to converter bolts but if it doesn't, what should I have on hand?
edit; found them, ARP 230-7305 set of 6. Ordered.

Weird they sell them in sets of six. Your converter should only have 3 bolt holes. The stock 4l80 has 6 bolt holes. As long as they work. Sell the extras.

Sent from my SAMSUNG-SM-T377A using Tapatalk



[Rocket Man]

Weird they sell them in sets of six. Your converter should only have 3 bolt holes. The stock 4l80 has 6 bolt holes. As long as they work. Sell the extras.

Sent from my SAMSUNG-SM-T377A using Tapatalk

I wasn't sure if I needed the pack of 6 or 3; the description said 6 are needed for trucks. Figured more is better, not enough is not an option. Since I'm going to replace the rear main seal while the trans is off, I also ordered an OEM rear main seal cover (12639250) with main seal installed to make that job easier, a flywheel turning tool to ease things when I'm under there so I don't have to use a big flathead screwdriver, a set of 3/8" extensions in 18,24 and 30 inch lengths for the bellhousing bolts since I heard you need around 48" and 3 gallons of Dex VI. I think that will do it. I hope so, I'm going broke lol.



[Rocket Man]

Ok NOW I'm broke. I remembered reading that my G80 Eaton rear differential was in need of a girdle to strengthen the bearing caps so they don't flex under high HP applications and it seems the TA performance ones are favored so I ordered this beauty:


I should have a nice looking rear end soon...my truck should that is. This has a drain and fill port and studs that tighten against the bearing caps to prevent flex and also increases capacity by 1/2 pint and average 15 degrees cooler operating temp. It's also the low-profile one so panhard bar clearance isn't an issue. Still looking for info on the front diff as far as failure prevention.



[95escahoe]

Ok NOW I'm broke. I remembered reading that my G80 Eaton rear differential was in need of a girdle to strengthen the bearing caps so they don't flex under high HP applications and it seems the TA performance ones are favored so I ordered this beauty:


I should have a nice looking rear end soon...my truck should that is. This has a drain and fill port and studs that tighten against the bearing caps to prevent flex and also increases capacity by 1/2 pint and average 15 degrees cooler operating temp. It's also the low-profile one so panhard bar clearance isn't an issue. Still looking for info on the front diff as far as failure prevention.

The AWD front diff on the Escalade/Denali is a ticking time bomb when stock, your best bet is doing more frequent fluid changes unless someone makes a front diff for more power


Sent from my iPhone using Tapatalk



[HiHoeSilver]

I wasn't sure if I needed the pack of 6 or 3; the description said 6 are needed for trucks. Figured more is better, not enough is not an option. Since I'm going to replace the rear main seal while the trans is off, I also ordered an OEM rear main seal cover (12639250) with main seal installed to make that job easier, a flywheel turning tool to ease things when I'm under there so I don't have to use a big flathead screwdriver, a set of 3/8" extensions in 18,24 and 30 inch lengths for the bellhousing bolts since I heard you need around 48" and 3 gallons of Dex VI. I think that will do it. I hope so, I'm going broke lol.

We're all going broke just reading your thread! Keep it up, Red. You're killing it.
