If I had one, I'd definitely want people to know. So I say flaunt it
Rocket Man's 02 Denali Build Thread AKA "THE BEAST"
- Thread starter Rocket Man
- Start date
Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.
OP
OP
I've got full time AWD so I just plain launch! If it was 2WD I'm sure I would have been. A lot of traction involved here.
95escahoe
Full Access Member
- Joined
- Aug 2, 2010
- Posts
- 5,155
- Reaction score
- 4,454
OP
OP
Dang good thing I posted that pic; I was able to correct the gap between the E and the R before the soapy water dried.
OP
OP
Yes it was for sure. 5 days worth.
TheAutumnWind
Full Access Member
- Joined
- Jan 8, 2015
- Posts
- 3,222
- Reaction score
- 1,921
oh my goodness red. this is nsfw.
I am so jealous
I am so jealous
Tonyrodz
Resident Resident
So it was those lower gaskets that was causing all your issues?
OP
OP
So the last things I had done before running into trouble and having to tear it back apart was the intercooler and lengthening the wires for the second connection on my Electronic Throttle Control. The IC had incorrect instructions of course so I improvised. The trans cooler was in the way so I decided to remove it's brackets and move it back, between the IC and the radiator. It fits barely and so far so good as far as working.
OP
OP
The IC pump mounted to the bumper bracket bolts on the passenger side. The view is looking up from the bottom. Here's a picture of one of the intake gaskets that caused me so much grief. LS engines have only used O-rings for intake manifold gaskets forever. Unless you're installing a Whipple. Then you need regular gaskets AND O-rings. I also had a 2-connector Electronic Throttle Control so I had to extend one of the harnesses. This kit was built for a 2003 since the 2002's had cable throttles for the most part. I also had to resort to my pop-up canopy since it started raining on the 3rd and 4th day. And finally... my tune being installed via my Autocal.
OP
OP
Yes, the extra set that was included in the kit that they forgot to add the instruction sheet for. There was an "addendum" for LS engines that said to use this extra set of gaskets along with the O-rings that were in the regular instruction book. I used a gasket sealer between the heads and the regular gaskets to hold them in place while I installed the lower intake manifold which had the O-rings. idiot at the plant forgot the "addendum". I thought the gaskets were an error that got put in the kit by mistake.
