DFM disabler released

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

KMeloney

Full Access Member
Joined
May 2, 2009
Posts
2,912
Reaction score
332
There’s another disabler aside from the Range unit? Huh. Didn’t know that.

Have a link to it?


Antonm

Full Access Member
Joined
Apr 2, 2024
Posts
211
Reaction score
232
So I ordered one of these Range units for my 2021 Yukon 5.3. I also ordered a Auto Stop Eliminator harness because I didn't realize that the Range module also disables Auto Start-Stop as well.

That being said, I contacted ASE to return my module, and they informed me that the Range unit keeps the trucks run in diagnostic mode, and when the truck is in diagnostic mode, the check engine light is suppressed. So if you ever had a problem, you wouldn't know...because the CEL doesn't come on. Any truth to this?

ASE is also saying that the Range unit has parasitic drain on the battery that is 1000x more than their unit. Which could lead to a dead battery situation if the vehicle sits for extended periods of time.

Not trying to start a beef between Range and ASE, but just wondering if there's some truth to this.

The range unit for 2021+ vehicles has been out for what, like a month now. They (a competitor) sure seem to know a lot about a product that has only been out for a very short time.
...

Last edited:

nick14226

Full Access Member
Joined
Nov 22, 2019
Posts
243
Reaction score
237
So I ordered one of these Range units for my 2021 Yukon 5.3. I also ordered a Auto Stop Eliminator harness because I didn't realize that the Range module also disables Auto Start-Stop as well.

That being said, I contacted ASE to return my module, and they informed me that the Range unit keeps the trucks run in diagnostic mode, and when the truck is in diagnostic mode, the check engine light is suppressed. So if you ever had a problem, you wouldn't know...because the CEL doesn't come on. Any truth to this?

ASE is also saying that the Range unit has parasitic drain on the battery that is 1000x more than their unit. Which could lead to a dead battery situation if the vehicle sits for extended periods of time.

Not trying to start a beef between Range and ASE, but just wondering if there's some truth to this.
Range said early beta units were drawing the battery down a bit when sitting over time. I never had an issue (daily driver) but they sent a revised version. Believe that was fixed before they released them for purchase.

As for the CEL being bypassed, can’t say for sure, but I can’t imagine that’s true.


Scarey

Member
Joined
Oct 15, 2024
Posts
45
Reaction score
20
Does anybody understand the 0 cylinder while coasting? Coasting is foot completely off the gas. Range says their new 007 disabler still allows this. In my mind 0 cylinder would be the engine is shut down. Is it braking off all the dead cylinders? Thats why range says they allow it, other wise it doesn’t slow as expected. Doesn’t quite make sense.


fondupot

Member
Joined
Oct 31, 2024
Posts
93
Reaction score
126
Location
South Carolina
The range unit for 2021+ vehicles has been out for what, like a month now. They (a competitor) sure seem to know a lot about a product that has only been out for a very short time.
...
I mean they could order one and test it like any other person I guess.

Range said early beta units were drawing the battery down a bit when sitting over time. I never had an issue (daily driver) but they sent a revised version. Believe that was fixed before they released them for purchase.

As for the CEL being bypassed, can’t say for sure, but I can’t imagine that’s true.
Good info.


Antonm

Full Access Member
Joined
Apr 2, 2024
Posts
211
Reaction score
232
I mean they could order one and test it like any other person I guess.

If they had the equipment and knowledge necessary to test it,,,then they would be making one with their name on it vice just giving all the market share to Range.

Range is owned by Holley as part of their tuning group. Very few ( if any ) companies in the automotive aftermarket have deeper pockets or more capability than Holley. Holley certainly has more money to throw at test gear / R&D than 4D tech ( the owners of auto stop eliminator ).

So I do find it a little suspicious that they instantly know everything about their competitors products. Not saying it couldn’t be true, but it wouldn’t be the first time a company talked trash about a competitor when they literally had no clue what they were talking about. And very rarely do the actual engineers ( the ones that do know) answer the phone to talk with customers.

POST EDIT: The Range device is not actually a DFM disabler, it's a DFM schedule modifier, parts of DFM (the 0-cylinder deceleration part) are left fully functional with this device installed. If fully disabling DFM all the time is what you want, then this device is not for you.

Last edited:

fondupot

Member
Joined
Oct 31, 2024
Posts
93
Reaction score
126
Location
South Carolina
If they had the equipment and knowledge necessary to test it,,,then they would be making one with their name on it vice just giving all the market share to Range.

Range is owned by Holley as part of their tuning group. Very few ( if any ) companies in the automotive aftermarket have deeper pockets or more capability than Holley. Holley certainly has more money to throw at test gear / R&D than 4D tech ( the owners of auto stop eliminator ).

So I do find it a little suspicious that they instantly know everything about their competitors products. Not saying it couldn’t be true, but it wouldn’t be the first time a company talked trash about a competitor when they literally had no clue what they were talking about. And very rarely do the actual engineers ( the ones that do know) answer the phone to talk with customers.

100% agree. Just wanted to share my experience with the group. My ASE arrived today, but I think I'll just return it and eat the shipping and restocking fee. My Range unit is supposed to arrive on Wednesday this week.


Marky Dissod

Full Access Member
Joined
Mar 3, 2023
Posts
2,022
Reaction score
2,814
Location
(718)-
Does anybody understand the 0 cylinder while coasting?
Coasting is foot completely off the gas. Range says their new 007 disabler still allows this.
In my mind 0 cylinder would be the engine is shut down. Is it braking off all the dead cylinders?
That's why range says they allow it, other wise it doesn’t slow as expected. Doesn’t quite make sense.
Deceleration Fuel Cut Off / DFCO (0%TPS) has been a feature since at least the 80s, likely earlier.
Normally, the engine twists thru the transmission, which twists the driveshaft, which twists the R&P,
which twists the axles and tires, which pushes the car down the road.

During DFCO, the entire sequence above is completely backwards.
If the road is effectively spinning the engine, then why waste ANY fuel at all?
(The answer, by the way, would be if/when it were necessary to use the engine as a brake, which is not always.)

Cylinder shutdown would reduce the engine braking even further by preventing the engine from inhaling any air at all -
it would just spin with minimal frictional losses, and it would stay warmer longer than if inhaled air without combusting it.
(Prior to cylinder shutdown, an engine in DFCO mode is effectively air cooling itself -
it inhales, squeezes without fuel or spark, does not 'bang', and exhales the same air, but that air is a bit warmer now.)


Kpwweb

Full Access Member
Joined
Dec 11, 2015
Posts
720
Reaction score
311
So I ordered one of these Range units for my 2021 Yukon 5.3. I also ordered a Auto Stop Eliminator harness because I didn't realize that the Range module also disables Auto Start-Stop as well.

That being said, I contacted ASE to return my module, and they informed me that the Range unit keeps the trucks run in diagnostic mode, and when the truck is in diagnostic mode, the check engine light is suppressed. So if you ever had a problem, you wouldn't know...because the CEL doesn't come on. Any truth to this?

ASE is also saying that the Range unit has parasitic drain on the battery that is 1000x more than their unit. Which could lead to a dead battery situation if the vehicle sits for extended periods of time.

Not trying to start a beef between Range and ASE, but just wondering if there's some truth to this.
I think part of the confusion here is that Range has two models—pre ‘21 that plugs into the OBD2 port, and a unit for post-‘21 models that fits between the ECM and wiring harness. I found both in my research.

I think what AES/ASE said applies partly to pre-‘21 models. It did have some parasitic draw on the battery. It would be hard to diagnose a vehicle when the OBD2 port is already taken. All this is related to the OBD2 port.

The unit for post-‘21 is a different beast entirely. And Kudos to Range for making it. If I can’t tune it like I did my 2016, then this is the next best thing. I love my unit and the control (perceived or not) it gives. After using it for almost three weeks, you will have to pry it …
