Wheel hub assembly replacement

Disclaimer: Links on this page pointing to Amazon, eBay and other sites may include affiliate code. If you click them and make a purchase, we may earn a small commission.

franksbanks

Member
Joined
Feb 19, 2013
Posts
72
Reaction score
1
Location
Arizona
Going to replace my wheel hub assemblies this weekend- my Yukon is making a horrendous noise while driving due to the bearings being really bad-

Got a pair of hub assemblies from Ebay yesterday- 110$ (pretty good price compared to autozoo)

I’m going to pick up all the additional tools in which I will need: need some verification that my list is correct:

T55 socket -brake calipers bolt
36mm socket-CV axle nut

Will I need to get a ball joint separator tool?

Misc specs needed:
What are the torque specs to re tighten the bolts afterward?

Feedback is appreciated


07Burb

GM fan for life
Staff member
Administrator
Supporting Member
Joined
Jan 3, 2011
Posts
50,389
Reaction score
17,299
To answer your question about the ball joint separator tool you should NOT need to touch your ball joints to replace your hub so no worries :waytogo:

What brand hub assembly did you end up getting?

OP
OP
franksbanks

franksbanks

Member
Joined
Feb 19, 2013
Posts
72
Reaction score
1
Location
Arizona
To answer your question about the ball joint separator tool you should NOT need to touch your ball joints to replace your hub so no worries :waytogo:

What brand hub assembly did you end up getting?

thanks for the quick response-

for some reason i was thinking the ball joint would get in the way- (ill have to replace them soon too)

here are the specs ont he hubs-

**Detroit Axle ** Complete Wheel Hub & Bearing Assembly

http://www.ebay.com/itm/17094840480...X:IT&_trksid=p3984.m1497.l2649#ht_2650wt_1170


07Burb

GM fan for life
Staff member
Administrator
Supporting Member
Joined
Jan 3, 2011
Posts
50,389
Reaction score
17,299
I've not heard of that brand. I hope they work out for you! They are definitely well priced and at least worth the shot :waytogo:

In order to replace the hub you should only have to removed the wheel, brake caliper and rotor to gain access to the hub so no removal of ball joint is required. It's a fairly straight forward job. Get a BFH (big friggin hammer) ready, though, as you may need it to break the hub assembly lose once you have the bolts out :)

OP
OP
franksbanks

franksbanks

Member
Joined
Feb 19, 2013
Posts
72
Reaction score
1
Location
Arizona
I've not heard of that brand. I hope they work out for you! They are definitely well priced and at least worth the shot :waytogo:

In order to replace the hub you should only have to removed the wheel, brake caliper and rotor to gain access to the hub so no removal of ball joint is required. It's a fairly straight forward job. Get a BFH (big friggin hammer) ready, though, as you may need it to break the hub assembly lose once you have the bolts out :)

I hope they last me for a few years- the previous owner(s) did not perform any maintenance on it... so now i have to replace all the worn parts out- which in return, will make it a more reliable truck- and thanks to the members on this site ( like 07Burb ), it has made it easier to get it done :worship:

Get a BFH (big friggin hammer) haha in deed :cheers:


Gzes

the drifting 2dr
Joined
Aug 9, 2011
Posts
5,433
Reaction score
51
Location
Wichita tx
Detroit axle is a good brand. Did my hubs on the exploder with that brand. I would do ball joints aswell since your already in there

OP
OP
franksbanks

franksbanks

Member
Joined
Feb 19, 2013
Posts
72
Reaction score
1
Location
Arizona
Detroit axle is a good brand. Did my hubs on the exploder with that brand. I would do ball joints aswell since your already in there

That’s good to know- I was a bit concerned about them, but I figured I would take the risk and test it out. If they did fail I wouldn’t mind replacing them again, as long as its not within the first year.. then I would be mad.. lol

I would do the ball joints, but it’s too late for them to get here in time-I like to save money by buying items on ebay & amazon- so I’m going to prioritize the hubs first- I don’t want to get stranded if the wheels lock up you know what I mean

I plan to order the upper/lower ball joints next week along with a replacement set of the idler arm & pitman

I’ll let you guys know how it goes once im done-

Last edited:

Gzes

the drifting 2dr
Joined
Aug 9, 2011
Posts
5,433
Reaction score
51
Location
Wichita tx
Ok yea when I was doing mine saw he had ball joints and said eff it went to the store got em and used my shop discount and did em


livingez_123

Full Access Member
Joined
Feb 18, 2013
Posts
1,798
Reaction score
112
Location
Sandy, OR
its best to break the axle nut loose with the truck still on the ground. you also have to remove the caliper bracket.


imi4tth3w

Full Access Member
Joined
Jan 14, 2010
Posts
386
Reaction score
60
Location
Texas
the caliper slide bolts should be a big torx head bolt and then the caliper bracket bolts are 18mm.
