Rocket Man's 2008 Bagged CC Silverado Build AKA "THE MACHINE"

[Rocket Man]

I just remembered my new air filter arrived yesterday so I installed it. I wasn't sure if it would fit so I attempted it with the plastic still on in case I needed to return it and it looked like it might so....I made it work. I kind of had to bend part of it but it's fine. And it's red so there's like 5 HP right there. I still haven't dropped the coin to add my VIN to my Autocal so Blackbear can tune it but I will when my tax return shows up.



[Tonyrodz]

It's one of the clones but I bought it from a US Ebay seller. https://www.ebay.com/itm/Tech2-II-scanner-with-candi-module-for-GM-cars-trucks-Saab-Isuzu/162888203878?ssPageName=STRK:MEBIDX:IT&_trksid=p2057872.m2749.l2649

Def let us know how it does.

The one in the pic... obviously

Wise ass!



[iamdub]

So much win lately.

Back to the Maestro- can you bypass the factory amp but keep the chimes functional? Basically divert just the low-level audio signals originally going to the amp to some RCAs to plug to a regular amp?



[05alive]

Yes, SWC, Onstar, amp or not, etc. plus it hooks into the OBDII port (actually you hardwire it into 2 wires from the back of the connector) so the HU can display tons of info (which a full-screen HU might but IDK because mine just had an AM/FM/CD). Through the maestro, it can display screens like full engine gauges, vehicle info screen with TPMS, climate control, parking assist, etc. Things that are controllable can be done through the HU. The Pioneer has a data connector on the back just for the Maestro. All in one box that's about the size of a PAC SWC. Plus it's programmable so if you want to do things like bypass your factory amp, delete OnStar or not use parking assist you can do that. You hook it to your computer and go to their website, then it sees what unit you have and asks for your vehicle info and what HU you have and walks you through your options. It's pretty damn nice.

View attachment 192555

That's awesome.



[05Single]

A

Actually the pocket back there is a perfect fit to slide the Maestro in and then tuck the wiring harness in. After doing it the second or third time I realized it was perfect if I did it right. On another note, I ended up using one of my old installer tricks to get the wiring down on the driver side- a speedo cable. Anybody ever use one of these for fishing wires down?

View attachment 192556

I'm getting ready to do my door speakers. What is this? Looks too thick

Edit: saw it's a Speedo cable



[Rocket Man]

So much win lately.

Back to the Maestro- can you bypass the factory amp but keep the chimes functional? Basically divert just the low-level audio signals originally going to the amp to some RCAs to plug to a regular amp?

Yes; it actually comes with it's own chimes speaker that you mount up in the dash, and you can control the volume on it too. No more chime through the door speaker.



[Rocket Man]

Def let us know how it does.

Wise ass!

It's actually a Vertronix, a Bosch subsidiary. The user manual is from Bosch. The thing is a beast; much bigger than I thought it would be. The main Tech 2 is as big as a pair of shoes. Plus there's the CANDI module. I just hooked it up and read all the DTC's in the truck. The ABS problems looked to be history and the current tests had all passed so I cleared them and the ABS light is off now. I'll see if it comes back. The service stabilitrac and service traction control messages are still there but I don't remember if I looked at those issues. I did see problems with the SIR system and current failed tests so I didn't clear those DTC's. And ever since I pulled half my fuses the other day, my TPMS message isn't there which is good since I read that that system can't be disabled by a tune although there are other ways to fake it out including a spoofing box. Anyway, I have half my messages gone and I have some info on my airbags that I can research. The thing is super easy to use; it walks you through the menus, you just need your RPO code list handy.



[Rocket Man]

Oh well I have ZERO patience dammit. I added the truck to my Autocal so it looks like a tune will happen next week if Blackbear has time. Kind of curious to see what improvement I'll see in the 4.8. It will be nice to get some better shifting and correct the speedo; it's off 5 mph in the city and 8+ on the highway.



[inmypassatlife]

Oh, you're the one that brought this one. I remember the owner posting all about it on the facebook bagged board...all's I'm saying is good luck



[Rocket Man]

Oh, you're the one that brought this one. I remember the owner posting all about it on the facebook bagged board...all's I'm saying is good luck

What do you mean by that?
