XLDenali06's Build Thread

[Rocket Man]

Here's an Escalade overlay on a Denali cluster with the Denali bezel. It needs an Escalade bezel. This overlay is for sale in the classifieds but it's only for an 01-02. $40 shipped.



[Tonyrodz]

Try here www.tahoeyukonforum.com/threads/escalade-vs-denali-vs-tahoe-cluster.48567/page-5
Third thread down. That may help you get an idea. It might work.



[adventurenali92]

I think @Red Rocket might have a better idea of fitment. He bought an overlay for an Esky, if I'm not mistaken, for his Denali, and it was a little off. One or two of the overlay cutouts was obscuring some letters, not much but it was. Hopefully he'll chime in.

Did he buy an esky bezel from a 2003+ esky? I just remembered his is a 2002 and the cluster changed shapes a bit from 2002 to 2003. The tachometer changed directions as well as the Trans temp gauge. Maybe that was why his wasn't an exact fit? I would assume if she gets the chrome bezeled face out of a 2005/2006 esky and lays it over her 2006 cluster it will be an exact fit. As thr gauge lines should match up.



[Tonyrodz]

Did he buy an esky bezel from a 2003+ esky? I just remembered his is a 2002 and the cluster changed shapes a bit from 2002 to 2003. The tachometer changed directions as well as the Trans temp gauge. Maybe that was why his wasn't an exact fit? I would assume if she gets the chrome bezeled face out of a 2005/2006 esky and lays it over her 2006 cluster it will be an exact fit. As thr gauge lines should match up.

No, he bought an aftermarket overlay that was for an Esky for his Denali cluster and it didn't match up exactly. He's selling it in the classifieds.



[Rocket Man]

It's right up there^^^^ . 01-02 only was what the mfr. said.



[adventurenali92]

Yeah I saw your classifieds post right after I posted my last comment.



[HiHoeSilver]

Here's an Escalade overlay on a Denali cluster with the Denali bezel. It needs an Escalade bezel. This overlay is for sale in the classifieds but it's only for an 01-02. $40 shipped.

The problem here is the faces. The overlay doesn't matter. They all fit any stock gauge face. Including the SS white set.



[Rocket Man]

The problem here is the faces. The overlay doesn't matter. They all fit any stock gauge face. Including the SS white set.

Not according to all the vendors. The 01-02 are slightly different. Every single place I've tried to buy them from say the same thing. It's not just the faces. The gauges themselves are slightly different.



[HiHoeSilver]

Not according to all the vendors. The 01-02 are slightly different. Every single place I've tried to buy them from say the same thing. It's not just the faces. The gauges themselves are slightly different.

Does your stock face (or any other aftermarket ones you've seen for yours) have the words FUEL Volts OIL or TEMP on them? everything I've seen just has the symbols, which are in fine locations on that silver one (I have seen these locations vary a little but always work with different bezels).

Also where it says RPM X 1000, usually I see it up to the left on the gauge, not underneath like that, although it ALMOST fits there, I guess.

My point is, it seems to me to be a layout /printing issue with that particular face, no?



[Rocket Man]

Does your stock face (or any other aftermarket ones you've seen for yours) have the words FUEL Volts OIL or TEMP on them? everything I've seen just has the symbols, which are in fine locations on that silver one (I have seen these locations vary a little but always work with different bezels).

Also where it says RPM X 1000, usually I see it up to the left on the gauge, not underneath like that, although it ALMOST fits there, I guess.

My point is, it seems to me to be a layout /printing issue with that particular face, no?

No. It is for an 01-02 Escalade. It just needs the Esky round gauge faces.
